vertical double row hinge boring machine is widely used in panel
type of furniture production. It is mainly used to drill hinge
holes on panel type furniture.
Adopts high precision Triple rail, to guarantee the precise
movement and adjustment of the vertical spindles. The imported
boring spindle guarantees to drill holes with high precision.
Main technical parameter:
wood drilling machine hinge boring machine
| Hingle Boring Machine | MZ73031 | MZ73032 |
| Max. diameter of holes | 50mm | 50mm |
| Depth of drilled holes | 0-60mm | 0-60mm |
| Distance between hole | 220-815mm | 220-750mm |
| Number of spindle | 3 | 3x2 |
| Rotation of spindle | 2840r/min | 2840r/min |
| Total motor power | 1.5kw | 1.5Kwx2 |
| Suitable voltage | 380V/50HZ 3Phase | 380V/50HZ 3Phase |
| Air pressure | 0.5-0.8Mpa | 0.5-0.8Mpa |
| Overall size | 800*750*1700mm | 1700*850*1700mm |
| Model | MZ73031 |
| Max drilling diameter | 50mm |
| Max drilling depth | 60mm |
| Number of drill | 3 Spindles |
| Spindle speed | 2840r/min |
| Motor power | 1.5kw |
| Air pressure | 0.6-0.8MPA |
| Dimension | 800*750*1700mm |
| Weight | 150kg |
1Taiwan brand drilling head
2Each head with φ35mm*1, φ3mm*2 blade tool
|
|
